In the paper, University of Arizona researchers Dr. Kathryn Volk and Professor Renu Malhotra present compelling evidence of a yet-to-be-discovered planetary body with a mass somewhere between that of Mars and Earth.

The mysterious mass has given away its presence — for now — only by controlling the orbital planes of a population of space rocks known as Kuiper Belt objects (KBOs).

While most KBOs — debris left over from the formation of the Solar System — orbit the Sun with orbital tilts that average out to what planetary scientists call the invariable plane of the Solar System, the most distant KBOs do not.

Their average plane, the authors discovered, is tilted away from the invariable plane by about 8 degrees.

In other words, something unknown is warping the average orbital plane of the outer Solar System.

“The most likely explanation for our results is that there is some unseen mass. According to our calculations, something as massive as Mars would be needed to cause the warp that we measured,” said Dr. Volk, lead author of the study.

The team analyzed the tilt angles of the orbital planes of more than 600 KBOs in order to determine the common direction about which these orbital planes all precess (precession refers to the slow change or ‘wobble’ in the orientation of a rotating object).

“KBOs operate in an analogous way to spinning tops,” Prof. Malhotra explained.

“Imagine you have lots and lots of fast-spinning tops, and you give each one a slight nudge. If you then take a snapshot of them, you will find that their spin axes will be at different orientations, but on average, they will be pointing to the local gravitational field of Earth.”

“We expect each of the KBOs’ orbital tilt angle to be at a different orientation, but on average, they will be pointing perpendicular to the plane determined by the sun and the big planets.”

“If one were to think of the average orbital plane of objects in the outer Solar System as a sheet, it should be quite flat past 50 AU,” Dr. Volk said.

“But going further out from 50 to 80 AU, we found that the average plane actually warps away from the invariable plane. There is a range of uncertainties for the measured warp, but there is not more than 1-2% chance that this warp is merely a statistical fluke of the limited observational sample of KBOs.”

“In other words, the effect is most likely a real signal rather than a statistical fluke.”

According to the calculations, an object with the mass of Mars orbiting roughly 60 AU from the Sun on an orbit tilted by about 8 degrees (to the average plane of the known planets) has sufficient gravitational influence to warp the orbital plane of the distant KBOs within about 10 AU to either side.

“The observed distant KBOs are concentrated in a ring about 30 AU wide and would feel the gravity of such a planetary mass object over time, so hypothesizing one planetary mass to cause the observed warp is not unreasonable across that distance,” Dr. Volk said.

This rules out the possibility that the postulated object in this case could be Planet Nine, predicted to be much more massive (about 10 Earth masses) and much farther out at 500 to 700 AU.

“That is too far away to influence these KBOs. It certainly has to be much closer than 100 AU to substantially affect the KBOs in that range,” Dr. Volk said.

Because a planet, by definition, has to have cleared its orbit of minor planets such as KBOs, the authors refer to the hypothetical mass as a planetary mass object.

The data also do not rule out the possibility that the warp could result from more than one planetary mass object.

Planet 10 makes its existence known by ruffling the orbital plane of distant Kuiper Belt objects. Image credit: Heather Roper / Lunar and Planetary Laboratory, University of Arizona.

“So why haven’t we found it yet? Most likely because we haven’t yet searched the entire sky for distant solar system objects,” the scientists said.

The most likely place a planetary mass object could be hiding would be in the galactic plane, an area so densely packed with stars that solar system surveys tend to avoid it.

“The chance that we have not found such an object of the right brightness and distance simply because of the limitations of the surveys is estimated to be to about 30%,” Dr. Volk said.

A possible alternative to an unseen object that could have ruffled the plane of outer KBOs could be a star that buzzed the Solar System in recent history.

“A passing star would draw all the ‘spinning tops’ in one direction,” Prof. Malhotra said.

“Once the star is gone, all the KBOs will go back to precessing around their previous plane.”

“That would have required an extremely close passage at about 100 AU, and the warp would be erased within 10 million years, so we don’t consider this a likely scenario.”
